Sensitivity (±10%) 25mV/N
Measuring Range 20KN
Non-linearity ≤1%
Resolution 450mN(rms)
Resonant Frequency ≥45kHz
Low Frequency 0.5Hz
Hammer head Weight 445gm
Hammer weight (total) 920g
Hammer Head Ø 32mm
Hammer Length 340mm
Output Connector BNC
Tips Supplied Soft, medium, hard
Excitation voltage +18 to +28V
Constant Current 2-10mA
Bias voltage 10-14VDC
Output Impedance ≤100Ω
