Rosemount Coplanar platform enables integration of primary elements, manifolds, and remote seal solutions.
Best-in-class performance with up to 0.05 percent high accuracy option.
IEC 62591 (WirelessHART) enables cost effective installations.
Local Operator Interface (LOI) offers easy to use configuration capabilities at the transmitter Protocols available include 4–20 mA HART, FOUNDATION Fieldbus, PROFIBUS PA, and HART 1–5 Vdc Low Power.
Selectable HART Revision prepares your plant for the latest HART capabilities while ensuring seamless integration with todays systems.
SIL2/3 safety certification to IEC 61508 is available with the full 4–20 mA HART offering to simplify compliance.
3 : -1000 to 1000 inH2O (-2,5 to 2,5 bar)
A : 4-20 mA with Digital Signal Based on HART Protocol
A : 3 in./DN 80 | 316L SST
0 : None, Flush Mount
F : 3 in. | ANSI/ASME B16.5 Class 150 | SST
D : Silicone 200
2 : Differential | SST
1 : 316L SST | Silicone
A : Glass-filled PTFE
A : Aluminum | 1/2-14 NPT
E6 : CSA Explosion-proof, Dust Ignition-proof, Division 2
