EJX118A Diaphragm Sealed Differential Pressure Transmitter
Output signal: -F =Digital communication (FOUNDATION Fieldbus protocol, refer to /Measurement
span (capsule):M =2 to 100 kPa (8 to 400 inH2O) /S =Always S /C =Always C /Coverflange bolts and nuts
materia: G =316L SST /Installation: -9 =Horizontal piping type and left side high pressure /Amplifier housing: 1 =Cast aluminum alloy /Electrical connection: 7 =1/2 NPT female, two electrical connections with a blind plug *3 /Integral indicator: D =Digital indicator *4 /Mounting bracket: B =304 SST 2-inch pipe mounting, flat type (for horizontal piping) /Process connection style: -W =Flush type /Flange rating: A2 =ANSI class 300 /Process connection size: 3 =3-inch (80 mm) /Flange materia: C =316 SST *11 /Gasket contact surface*1: 2 =Flat (no serration) /Wetted parts material*10: SW =316L SST 316L SST /Flushing connection ring*2: 0 =None /Extension: 0 =None /Fill fluid*5: -D =For oil-prohibited use (fluorinated oil)*5
–20 to 120°C –10 to 60°C /Capillary connection: A =Side of diaphragm seal unit /2 =Always 2 /A = 10 m
