UNIK 5000
Pressure sensing platform
PTX =Main Product Variant: 4-20 mA Pressure Transmitter
5 = Product Series: UNIK 5000
0 =Diameter and Materia: 25mm Stainless Steel
R = Electrical Connector :M20 x 1.5 Inline Female Conduit Demountable
2 = Electronics Option: 4 to 20 mA 2-wire (PTX)
TB =Compensated Temperature Range: -20 to +80 °C (-4 to +176 °F
A2 =Compensated Temperature Range: Improved
CA = Calibration: Zero/Span Data
H1 =Hazardous Area Approval : IECEx/ATEX Intrinsically Safe ‘ia’ Group IIC
PE = Pressure Connector: 1/4 NPT Female Note 3 / with 6 meter cable / range 0 .... 30 BAR
