FB-CPU1.1 Card
Microcontroller: Renesas H8-2318 at 25Mhz
RAM memory: 4 Mbit buffered with lithium battery
FLASH memory: 2 Mbit
Ethernet outlet: 10/100BaseT
with RJ 45 connector
Watch Dog: external
Hot Plug YES
Redundancy YES
Supply voltage: 22-29Vdc
Absorption in idle status: 70mA
Operating temperature: -10 / +50 °C
Storage temperature: -30 / +80 °C
Maximum humidity: 95% without condensate
